Bradco BC72 - Page 19

10800 6-25-10-2
NO REQ'D PART NO. DESCRIPTION
1 9 1044 .38" UNC x 1.25" Hex Capscrew
2 9 1800 .38” Hard Flat Washer
3 9 2005510 .38” UNC Flange Lock Nut
4 1 104420 Hinge Mounting Cover
5 1 17941 Hinge
6 1 108547 Replacement Cover with Decals
7 4 1021 .31” UNC X .75” Hex Capscrew
8 4 1502 .31” Lock Washer
9 4 1513 .31” Flat Washer
10 1 25453 Manual Tube
11 1 89968 Shackle
12 1 18169 Lift Limiting Chain
13 1 17846 Rear Access Cover (72” Cutter Service Part ONLY)
2 1953 .38" UNC X .75" Flange Hex Capscrew
14 1 15321 Blade Access Cover
2 1953 .38" UNC X .75" Flange Hex Capscrew
15 1 15329 72" Cutter
1 106299 78” Cutter
16 59 15326 Front Chain (72” Cutter)
63 15326 Front Chain (78” Cutter)
17 1 17348 72" Front Chain Retainer
1 106342 78” Front Chain Retainer
18 1 1514 .38" Flat Washer
19 1 1611 Cotter Pin
20 2 1793 Cotter Pin
21 2 17390 Special Nut (Torque to 450 ft. lbs.)
22 1 15324 Stump Jumper Hub
23 2 18515 Double Edged Blade (72" Rotary Cutter)
- 17847 Optional Banana Blade (72" Rotary Cutter)
2 106312 Double Edged Blade (78" Rotary Cutter)
24 2 17389 Blade Mounting Bolt
ROTARY CUTTER ASSEMBLY
72 & 78” HIGH FLOW CUTTER ASSEMBLIES
