LUBRICATION
H
H
9011
4-15-03
GENERAL INFORMATION
Economical and efficient operation of any machine is dependent upon
regular and proper lubrication of all moving parts with a quality lubricant. Neglect
leads to reduced efficiency, wear, breakdown, and needless replacement of parts.
WEEKLY
The oil level in the gear box should be checked once a week. Fill as
necessary with 80-90 weight gear lubricant.
TO CHECK:
Remove pipe plug from end of gearbox. Lubricant should be at the same
level as the plug.
TO ADD:
Remove pipe plug from end of gearbox. Remove filler plug from top end of
gearbox and add 80-90 weight gear lubricant up to the same level as the pipe
plug. Replace pipe plug and filler plug.
IMPORTANT: DO NOT OVERFILL, AS TOO MUCH LUBRICANT MAY RUP-
TURE THE GEAR BOX SEALS.
FILLER PLUG
PIPE PLUG
ADD LUBRICANT TO
THIS LEVEL
GEARBOX
