Bradco BC72 - Page 23

10804 10-12-06
HYDRAULIC KIT #105779
NO REQ'D PART NO. DESCRIPTION
1 1 19638 Male Coupler .75” Body 12FBo
2 1 22520 Female Coupler .75” Body 12FBo
3 2 37060 Hose Assembly .75” X 88” 12MBo-12FJX
4 1 38151 Hose Assembly .38” X 94” 6FJX-8MBo
5 1 84923 Male Coupler .38” Body 8FBo
6 1 32549 Dust Cap
HYDRAULIC KIT #105780
NO REQ'D PART NO. DESCRIPTION
1 1 84922 Male Coupler .62” Body 12FBo
2 1 84921 Female Coupler .62” Body 12FBo
3 2 37769 Hose Assembly .75” X 108” 12MBo-12FJX
4 1 38162 Hose Assembly .38” X 112” 6FJX-8MBo
5 1 84923 Male Coupler .38” Body 8FBo
6 1 32549 Dust Cap
HYDRAULIC KIT #105781
NO REQ'D PART NO. DESCRIPTION
1 1 22519 Male Coupler .50” Body 12FBo
2 1 22518 Female Coupler .50” Body 12FBo
3 2 37060 Hose Assembly .75” X 88” 12MBo-12FJX
4 1 38151 Hose Assembly .38” X 94” 6FJX-8MBo
5 1 84923 Male Coupler .38” Body 8FBo
6 1 32549 Dust Cap
HYDRAULIC KIT #105782
NO REQ'D PART NO. DESCRIPTION
1 1 19638 Male Coupler .75” Body 12FBo
2 1 22520 Female Coupler .75” Body 12FBo
3 2 37060 Hose Assembly .75” X 88” 12MBo-12FJX
4 1 38151 Hose Assembly .38” X 94” 6FJX-8MBo
7 1 84928 Female Coupler .38” Body 8FBo
8 1 32548 Dust Plug
HYDRAULIC KIT #105783
NO REQ'D PART NO. DESCRIPTION
1 1 16434 Male Coupler 1.00” Body 16FBo
2 1 16433 Female Coupler 1.00” Body 16FBo
3 2 37060 Hose Assembly .75” X 88” 12MBo-12FJX
4 1 38151 Hose Assembly .38” X 94” 6FJX-8MBo
5 1 14176 Male Coupler 50” Body 8FBo
6 1 17921 Dust Cap
9 2 30292 Straight Adapter 12FBo-16MBo
HYDRAULIC ASSEMBLY
HYDRAULIC ASSEMBLIES FOR HIGH FLOW DRIVES
E
E
