ITEM REQ’D PART NO. DESCRIPTION
1 1 101414 Spindle Dust Cap
2 1 10047 1.00” UNC Castle Nut
3 1 1706 1.00” Hard Flat Washer
4 1 33715 Tapered Roller Bearing
5 1 1614 Cotter Pin
6 1 33714 Tapered Roller Bearing
7 1 15511 Seal
8 1 101115 Wheel Yoke
9 1 24513 Support Arm
10 5 1092 .50” UNC x 2.00 Hex Capscrew, Grade 8
11 10 1516 .50” Hard Flat Washer
12 1 24530 .38” x 9.00” x 21.00 Plate
13 5 1841 .50” UNC Locknut, Grade 8
14 1 101195 Foam Filled Wheel & Tire Assembly
1 6616 Replacement Zerk
15 1 10105 Wheel Shaft/Nut Assembly
16 Varies 6562 Spring Washer
MOUNTING KIT INSTALLATION
WHEEL KIT ASSEMBLY #24518
10042
6-25-10-2
