Bradford White ACCESSORY MODULE - Page 42

Leak Sensor Installation
-42-
Prepare the Accessory Module for the Leak Sensor – cont’d
Step 5: Loosen the screw labeled “LK,” as shown in Figure 56.
Remove the Leak Sensor Resistor
Step 6: Using needle nose pliers, remove the Leak Sensor resistor from the Accessory Module and
discard. This is shown in Figure 57.
Figure 56
Figure 57
Transformer
Wire Harness
Accessory
Module
Leak Sensor
Resistor
Philips head
screwdriver
Transformer
Wire Harness
Accessory
Module
Leak Sensor
Resistor
