Start-up Procedure
-68-
Fix the Accessory Module Cover in Place
Step 3: Tighten both Accessory Module cover screws, as shown in Figure 104.
Route the Various Wire Harnesses
Step 4: Route the wire harnesses along the jacket and group them using the included wire ties. This is
shown in Figure 105.
Figure 104
Figure 105
Accessory
Module
Philips head
screwdriver
Group the Wire
Harnesses with the
Included Wire Ties
Wire Harnesses
Water Heater
Jacket
