Braemar Integrated Cooling
Effective from January 2011 V10 –
Updated 2
nd
April 2011
Page 2
CONTENTS
Preface 3
Typical Installation 4
Indoor Cooling Coil Installation 5
Outdoor Unit Installation 10
Refrigerant Pipe-work 11
Electrical Wiring 12
Spectrolink Set Up 15
Zoning 17
Start up & Commissioning 20
Refrigerant Charge 21
Commissioning Sheet 22
Maintenance & Service 23
Before Calling for Service 24
Troubleshooting 25
Operation Tips 26
Technical Specification 27
Removal & Disposal Warning 28
Connection to Other Gas Ducted Heater Brands 28
Contact Details 29
NOTE: HOMEOWNER
Please keep this manual in a safe place along with a copy of your receipt and all relevant
certificates of compliance relating to the installation work performed.
The Braemar Integrated Cooling unit is a refrigerated cooling only,
split type air conditioning system, designed specifically for connection
to a Braemar “TH Extra Air” Series gas ducted heating unit, using
ONLY Braemar Spectrolink Comfort Control.
Read this manual before installation and operation.
Make sure that it is kept for later references.
Installation training is available from Seeley International for
qualified and licensed installers; please contact your local office for
training dates.
