NOTES FOR PRODUCT DISPOSAL
The device contains electronic components and cannot therefore be disposed of as normal household waste. For the disposal
procedure, please refer to the local rules in force for special waste.
BRAHMA S.p.A.
Via del Pontiere, 31
37045 Legnago (VR) - ITALY
Tel. +39 0442 635211 - Fax +39 0442 25683 16/03/18 Subject to amendments without notice
http://www.brahma.it
E-mail : brahma@brahma.it
2704_r03 5/5
ATTENTION --> Company Brahma S.p.A. declines any responsibility for any damage resulting from Customer tampering with the device.
TYPE REFERENCE
EG12 * S R P * G FD 8 P D 230/50-60
Supply voltage
Type Description
110/50-60 110Vac/50-60Hz
230/50-60 110Vac/50-60Hz
Type Description
A Fast opening valve.
S Fast, silent opening valve.
L
Slow, silent opening valve
(this version is inclusive of
flow adjuster).
Valve fitted with equipment for
flow adjustment.
Valve inclusive of pressure
plug G1/4” size.
Gas pressure switch type
Type Description
P Fixed setting
PR adjustable setting
Gas pressure switch position
Type Description
D Right
S Left
Connection type
Type Description
2C
Connection with two core
cable-IP65.
3C
Connection with three core
cable-IP65.
FP Connection with flat fast-on.
FD
Connection with fast-on for plug
DIN43650-IP65.(GFD IP40)
MO
Connection with terminal
board-IP40.
Type
Test pressure point position
Type Description
7 Inlet left
8 Inlet right
5 Outlet (“S” and “L” versions only)
Type
Descrizione
A Supply in alternate current.
C Supply in direct current.
G
Supply in alternate current, but valve
operates in direct current thanks to an
embodied rectification bridge.
(“MO” and “FD” connection versions only)
