BRAHMA MICROFLAT Series - Connection Diagram

6/13 3997_r02
CONNECTION DIAGRAM
TYPES WITH MANUAL RESET WITHOUT FAN
THERMOSTAT FUSE BURNER LOCK
-OUT FIRST GAS SECOND GAS SAFETY RESET MAIN
SIGNAL VALVE VALVE THERMOSTAT SWITCH
TYPE CM11F
TYPE SM11F
TYPE MM11F
TYPE TM11F
TYPE MM51F
TYPE CM12F
TYPE TM12F
TYPE MM12F
NOTA: the limit thermostat has to be wired in series to the live.
