BRAHMA MICROFLAT Series - Page 9

3997_r02 9/13
TYPES WITH ELECTRICAL RESET AND FAN
TYPE CE31F
TYPE SE31F
TYPE ME31F
TYPE TE31F
TYPE CE32F
TYPE ME32F
TYPE TE32F
THERMOS
TAT FAN AIR PRESSURE FUSE BURNER LOCK
-
OUT FIRST GAS SECOND GAS SAFETY MAIN
SIGNAL VALVE VALVE THERMOSTAT SWITCH
NOTA: the limit thermostat has to be wired in series to the live.
