SUSPENSION ADJUSTMENTS
Suspension Settings
Setting Front Rear
Ride Height
133.35 mm (5.25 in.) from lowest
part of A-arm pivot
106.35 mm (4.1875 in.) from bottom center of rear
most chassis tube under transmission
Camber
-1 degree -1 degree 15 mins
Toe
1 mm (.040 in.) toe out each side 1.5 mm (.059 in.) toe out each side
Tire Pressure
18 PSI, 12 PSI minimum 20 PSI, 12 PSI minimum
