ASSEMBLY INSTRUCTIONS (CONTINUE)
Step 11
a) Attach the Left Cabinet Side Panel (38) with four screws (B), two screws for the
bottom edge and two screws for the rear side edge.
b) Repeat the same procedure for the Right Cabinet Side Panel (32) as shown in the
diagram.
Step 12
a) With the help of another person, lift and place the Body Assembly (1) onto the
prepared frame unit and secure with four screws (A) as shown in the diagram.
b) Ensure all screws are tightened.
38
32
1
M6X12 ...4 PCS
A.
