BRAND-MAN Rustler2 - Steps 17-18: Door Handles and Legs

18
ASSEMBLY INSTRUCTIONS (CONTINUE)
Step 17
a) Attach one Side Cabinet Door Handle (41) to bottom edge of Left cabinet
Door (45) with two screws (B) as shown in the diagram.
b) Attach Left Cabinet Door Support (4 ) to Left Cabinet Door (45) with two
screws (B).
c)
Install Left Cabinet Door Leg Supports (44) to bottom of Left Cabinet Door (45) with
d)
Step 18
a) To attach the Left Cabinet Door (45) onto the left side cabinet insert the
door pin located on the right of the Left Cabinet Door (45) into the left
side of the Body Assembly.
b) Then fasten with one step screw (G) through the Left Cabinet Door Pin
Support (40) into the Left Cabinet Door (45) as shown in diagram.
41
45
45
44
c
Attach
four step screws (D), flat washers (F) and self-lock nuts(E) as shown in the diagram.
two screws (B) for each.
37
37
Left Cabinet Door Leg (37) to both Left Cabinet Door Leg Supports (44) with
35
