1. REMOVE RIGHT HAND FENDER, SEAT PLATE AND BACK PLATE. THE TWO BOLTS
HOLDING THE PRESSURE REGULATOR BLOCK MUST BE REMOVED. LOOSEN THE
LOCKING NUT ON THE 90° ADAPTER, BUT DO NOT REMOVE THE HOSE.
2. INSTALL THE 2 STUDS FROM AS SHOWN. BE SURE NOT TO LOOSE OR DAMAGE O-RINGS
ON THE BOTTOME OF PRESSURE REGULATING BLOCK
REMOVE
TWO BOLTS
LOOSEN NUT
