Page 22
Pump Module Parts List
* Apply red #271 Thread Locker Loctite
®
to the four hex bolts (items 27 and 28) if a blue nylon patch is not present on
the bolts when retrotting an M268-0113 pump assembly. Loctite
®
is available from The Braun Corporation under part
number 11522-1.
t Indicates items available for replacement part purposes only. These items are not included with replacement pump
modules.
Item Qty. Description
1 Pump Module (complete), 12 Volt, Rear 917-5516RNA 917-5516FNA
1 1 Plate, Backing / Mounting - Rear 985-2501RN 985-2501FN
2 1 Cover, Pump, 2-Piece - Back / Bottom
(915-0513RNAPT or 915-0513FNAPT Includes Items 2 and 16 - 22)
915-0513RNPT 915-0513FNPT
3 1 Cover, Pump - 2-Piece - Top / Front
(915-0519RNAPT or 915-0519FNAPT Includes Items 3 and 39 - 52) 915-0519RNPT 915-0519FNPT
Part Numbers of Items Identical on all Lift Models
Item Qty. Description Part No.
4 1 Pump Assembly (M268-0113) 12V-120G - Dual Relief / ARS (Includes Items 5 & 6) 31038-12V
5 1 Power Cable, Up Solenoid to Motor 29049
6 1 Solenoid, Up - 4-Post - Trombetta (Flat Mount) 31374
7 1 Diode Assembly, Up Solenoid 73906A
8 2 Nut, #10-32, Serrated Flange 83080
9 2 Fitting, Male 7/16-20 O-Ring to Male 7/16-20 JIC 37° 24504
10 1 Elbow, Female Swivel 7/16-20 JIC 37° to (2) Male 7/16-20 JIC 37° 26579
11 1 Switch, Pressure 31199
12 1 Control, Hand Pendant Assembly (See below for available options)
12a - Control, Hand Pendant Assembly - Non-Shielded Cable - Straight tSee note below 32832A
12b - Control, Hand Pendant Assembly - Shielded Cable - Straight tSee note below 32833A
12c - Control, Hand Pendant Assembly - Shielded Cable - Coiled tSee note below 32421A
13 1 Control Board Assembly 100159-001
14 8 Standoff, Snap-In 31011
15 1 Switch, Push Button 31753
16 1 Recepticle, Clip On 28803
17 1 Lens, Threshold Warning - Red 30704
18 1 Decal, Warning / Pressure Relief Valve (Not shown) 22249
19 1 Spacer, Lens - NHTSA 31386
20 1 Metal Ring Base - Lamp 30971
21 1 Socket, Lamp 30703
22 3 Screw, #8-32 x 1/2” Pan Head Phillips - Thread Cut 30974
23 1 Bulb, Light 19841
24 1 Diode, Green LED, Panel Mount 29545
25 4 Rivet, Snap - .124” Hole x .197”/.236” Thick 29874
26 2 Washer, 5/16” Flat 10063
27 2 Bolt, 5/16-18 x 3/4”, Nylock, Hex * See note below 29608
28 2 Bolt, 5/16-18 x 1/2”, Nylock, Hex * See note below 10012
29 1 Cable, Ground 22166A
30 1 Washer, 5/16” External Tooth 16368
31 1 Beeper, Constant - High Output 33251
32 1 Switch, Toggle 31787
33 1 Decal, Lift Power - On/Off (Not shown) 21494
34 1 Stud, Power Feed 26084
35 1 Rubber Boot, Red tSee note below 82046
36 1 Harness, Lift Interlock Connection 32639A
37 1 Wire Assembly, Lift Stowed Connection tSee note below 32638A
38 1 Pump Handle with Grip 17206A
39 3 Rivet, Pop, SD43BS - 1/8” - .13”/.19” 12954
40 1 Plug, Window - Clear 30443
41 1 Stud, Wing Head - 1/4 Turn 28804
42 1 Retainer, Push On 28805
43 1 Washer, Nylon, 1/4” I.D. x 11/16” O.D. x .030” 12690
44 1 Clip, Pump Handle - Top 915-5517
45 1 Clip, Pump Handle - Bottom 915-5518
46 1 Decal, Manual Instructions - Public (Not shown) 31412
47 1 Decal, Removal / Installaton - Pump Cover (Not shown) 29051
48 1 Decal, Warning - Control Board Damage - ESD (Not shown) 30787
49 1 Decal, Removal / Installation Pump Handle (Not shown) 29052
50 1 Decal, Installation & Warning - Hydraulic Pressure Switch (Not shown) 27154
51 1 Decal, Dual Relief Adjustment (Not shown) 32201
52 1 Decal, LCD Lift Codes (Not shown) 32410
53 1 Cable, Pump Module Power Hookup (Not shown - see Wiring Diagram) 26082A-4
54 1 Harness, Power - Stow Interlock (Not shown - see Wiring Diagram) 915-4530RNA
55 1 Harness, Interlock / Lighting (Not shown - see Wiring Diagram) 915-4533NA
56 1 Harness, Up / Down Solenoid (Not shown - see Wiring Diagram) 915-2533NA
57 1 Harness, Threshold Switch Extension (Not shown - see Wiring Diagram) 915-4534NA
58 1 Harness, Hand Control - Pump Housing to Circuit Board (Not shown - see Wiring Diagram) 100245-001
Part Numbers of Items Dedicated per Lift Model
NL915IB, NL916IB,
NL917IB, NL918IB
and NL919IB
NL915FIB, NL916FIB,
NL917FIB, NL918FIB
and NL919FIB
