Bravo MIG 110 - 4 Components List; Power Source Art. 484: See File Esp484.Pdf Enclosed at the End of the Manual; Components Table: See File Esp484.Pdf Enclosed at the End of the Manual; 5 Electrical Diagrams

CEBORA S.p.A. 9
3.302.140 21/05/03
4 - COMPONENTS LIST
4.1 - Power source art. 484 : see file ESP484.pdf enclosed at the end of the manual.
4.2 - Components table: see file ESP484.pdf enclosed at the end of the manual.
5 - ELECTRICAL DIAGRAMS
5.1 - Power source art. 484 : see file SCHE484.pdf enclosed at the end of the manual.
5.2 - Control board (41) code 5.600.817/A.
5.2.1 - Topographical drawing.
5.2.2 - Connector table.
Terminals Function
A1 input start signal from torch button.
A2 wire feeder motor command output.
A3 control board (41) common supply input.
B1 NU
B2-B3 output contactor (50) command output.
M12179B, MB120A, WFW12179, 117-092, 83-363 (Mig 110)
