14
Using the tables and descriptions below as a guide, set your selected discipline and
button layout into the TX-101 transmitter.
The Transmitter identity and operation are set via the three 8 position dipswitches
accessed by removing the battery cover and the batteries.
Transmitter Dipswitch Settings
Switch numbers are printed on the body of the dipswitch.
TOP
The (7) CHN switches must match between TX, Rx and Counter – Used to set frequency
MIDDLE
The (5) CODE switches must match between TX and RX
BOTTOM
SKEET / SPORTING - Instant Release
INTERNATIONAL SKEET – Random Delay 0-3 Seconds (Ignores any set delay)
AMERICAN SKEET- Random Delay 0-1 second (Ignores any set delay)
1/6
th
SECOND DELAY added before the first release
HOLD VOICE MODE (Repeats last call if mic. detected)
