8
(3.2) RX-101 Receiver Set Up
The receiver identity and operation are set via the three 8 position dipswitches.
Receiver Dipswitch Settings
Switch numbers are printed on the body of the dipswitch.
SW3
The (7) CHN switches must match between TX, RX and Counter- Used to set RF frequency
SW2
(5) CODE switches must match between TX and RX
Receiver relay ‘TRAP1’ responds to Transmitter button ‘A’
Receiver relay ‘TRAP1’ responds to Transmitter button ‘B’
Receiver relay ‘TRAP1’ responds to Transmitter button ‘C’
Receiver relay ‘TRAP1’ responds to Transmitter button ‘D’
Receiver relay ‘TRAP2’ responds to Transmitter button ‘A’
Receiver relay ‘TRAP2’ responds to Transmitter button ‘B’
Receiver relay ‘TRAP2’ responds to Transmitter button ‘C’
Receiver relay ‘TRAP2’ responds to Transmitter button ‘D’
SW1
Receiver relay ‘TRAP1’ closed time= 0.25 sec.
Receiver relay ‘TRAP1’ closed time= 0.8 sec.
Receiver relay ‘TRAP2’ closed time= 0.25 sec.
Receiver relay ‘TRAP2’ closed time= 0.8 sec.
Receiver relay ‘TRAP1’ re-cock time= 0.5 sec.
Receiver relay ‘TRAP1’ re-cock time= 1.5 sec.
Receiver relay ‘TRAP2 re-cock time= 0.5 sec.
Receiver relay ‘TRAP2’ re-cock time= 1.5 sec.
CHN Channel Dipswitches
The CHN dipswitch settings on both the Receiver and Transmitter must match for the
system to operate.
These will be preset when the unit is shipped and so under most circumstances should
not need you to change them.
