Main power quality should be that of a typical commercial and/or
hospital environment. If the user of the VPULSE requires continued
operation during power main interruptions, it is recommended that the
VPULSE be powered from an uninterruptible power supply or a battery.
If improper operation occurs, it may be necessary to position the
VPULSE further from sources of power frequency magnetic fields or to
install magnetic shielding. The power frequency magnetic field should
be measured in the intended installation location to ensure that it is
sufficiently low.
Voltage dips,
short interrup-
tions and voltage
variations on
power supply
input lines
IEC 61000-4-11
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
< 5 % U
(>95% dip in U)
for 0,5 cycle
40% U
(60% dip in U)
for 5 cycles
70% U
(30% dip in U )
for 25 cycles
< 5 % U
(>95% dip in U)
for 5 sec
3 A/m
< 5 % U
(>95% dip in U)
for 0,5 cycle
40% U
(60% dip in U)
for 5 cycles
70% U
(30% dip in U)
for 25 cycles
< 5 % U
(>95% dip in U)
for 5 sec
3 A/m
Note: U is the A/C main’s voltage prior to application of the test level.
Rated Maximum
Output Power of
Transmitter watts
0.01
0.1
1
10
100
Separation distance metres
150 kHz to 80 MHz
d=1,2√P
150 kHz to 800 MHz
d=1,2√P
800 MHz to 2,5 GHz
d=2,3√P
0,12
0,38
0,12
3,8
12
0,12
0,38
0,12
3,8
12
0,23
0,73
2,3
7,3
23
