brent 1082 - Electrical System Schematic

Brent 1082/882 — Maintenance
4-22
GRAIN CART WIRES
White -- Ground
Green -- Right amber fl ashing lamp
Yellow -- Left amber fl ashing lamp
Brown -- Tail light
Black -- Interior & Auger Lights
Red -- Brake Lights
Electrical System Schematic
(July 2015)
