Brent 1082/882 — Parts
5-11
Please visit www.unverferth.com/parts/ for the most current parts listing.
ITEM DESCRIPTION PART NO. QTY. NOTES
Hub & Spindle Assembly (Green) 284269G
Hub & Spindle Assembly (Red) 284269R
Spindle Dia. 4.50" 280240 1 Not Shown
1 Seal - 4.375" I.D. 92455 1 43605SA
2 Outer Cup 92462 1 HM212011
3 Outer Bearing Cone 92464 1 HM212049
4 Hub Cap 92465 1
5 Cotter Key, 3/8 x 4 9391-090 1
6 Nut 92470 1
7 Washer 92472 1
8 Capscrew, 5/16-18 UNC x 1/2 9390-026 4
9
Hub (Green) 266455G
1 Includes Items 2,10
Hub (Red) 266455R
10 Inner Cup 92476 1 HM218210
11 Inner Bearing Cone 92545 1 HM218248
12 Ring 14442 1
13 Capscrew, 7/8-14UNF x 4 97043 10 Grade 8
14 Flat Washer, 7/8 97041 10
15 Pin Guide 7/8" Dia. x 4 3/4 266459 2
16 Gasket 284230 1
Hub — Duals
(November 2015)
