ITEM # QTY. PART # DESCRIPTION
32331K for IE & IE-R Models
1 1 32333M for IE-X Models Plasti-Bat
2 2 22135X Bat Pin
3 2 Item 2 & 3 sold as set Bat Pin Wing Nut
22012M for IE & IE-R Models
4 1 22017T for IE-X Models Wheel Head Assembly
4a 1 4a, 4b & 4c sold as assembly only see item 4 Wheel Head
4b 1 4a, 4b & 4c sold as assembly only see item 4 Wheel Head Shaft & Bearing
4c 1 4a, 4b & 4c sold as assembly only see item 4 Bearing Housing
5 3 5/16-18 x 1 1/2 Hex Bolt Wheel Head Mounting Bolt
6 3 5/16-18 Flange Nut Wheel Head Mounting Nut
7 3 5/16-18 X 1 3/4 Flat Head Slotted Machine Screw Table Top Mounting Bolt
8 3 5/16-18 Flange Nut Table Top Mounting Nut
9 1 22281F Splash Pan Front
10 1 Items 9 & 10 sold as a set Splash Pan Back
11 1 08024R Table Top IE Black
12 1 08029A Steel Frame
13 1 22048J Large Drive Pulley
14 1 5/16-18 x 5/8 Square Head Drive Pulley Lock Bolt
15 1 3/16 x 1 1/4 Key Stock Drive Pulley Shaft Key
16 1 22766F Drive Belt
17 1 08770R Belt Guard
18 4 1/4-20 x 3/4 Hex Bolt Belt Guard Screws
1 22689H for IE & IE-R Wheel
19 1 22765E for IE-X Wheel Motor
20 1 22626X (set screw included) Motor Drive Pulley (Small Pulley)
1/4-20 x 1/4 Allen Set Screw (included with motor
21 1 pulley part # 22637V)
22 6 1/4 Fender Washer Motor Mounting Fender Washer
23 4 5/16-18 Flange Nut Motor Mounting Flange Nut
24 2 22306M Motor Mounting Bushing
25 1 22134W Fuse Holder
26 1 08780C Reversing Switch (IE-R & IE-X only)
27 1 22117A Power Switch
28 1 22140R PCB Controller
29 4 #6 1/2" Pan Head Phillips Screw PCB Controller Screws
30 3 22822A IE Leg
31 3 22695P Frame Leg Plug
32 6 6-20, 1/2" Self-Tapping Screw Leg Extension Set Screws
33 1 22035R Foot Pedal complete
34 1 22278C Foot Pedal Tension Hardware & Arm
35 4 2273W (Mtg. Screws Included) Foot Pedal Foot
36 4 6/32 X 3/8 Phillips Head Machine Screws Foot Pedal Foot Mtg. Screw
37 1 22945T Foot Pedal Cord
PARTS LIST
MODELS:
IE, IER, and IEX
