EN - Instruction Manual Brew Monk Titan
• The blue valve, on the circulation pipe, in horizontal position closes the ball valve. The blue
valve, on the circulation pipe, in vertical position opens the ball valve.
• Switch off the pump when you close the blue valve for longer than 5 seconds.
• Always close the blue valve and switch off the pump before removing the curved pipe (11).
• Do not run the pump during wort boiling.
• It is not recommended to use the pump for pumping the wort after cooling, as there is no
lter on the pump inlet. This can cause brew debris to enter the pump, potentially blocking
and damaging the system.
2.2 Bazooka Filter Assembly
Attach the bazooka lter (12) on the male thread inside the Brew Monk and screw the bazooka
lter on (see picture below).
2.3 Overflow Pipe Assembly
2.3.1 Malt Pipe Assembly Outside the Brew Monk
Step 1
Place male thread (D)
through bottom malt
screen (B) and attach with
the nut (C).
1 x top malt screen
1 x bottom malt screen
1 x nut
1 x telescopic overow pipe
A
B
D
C
A
C
D
B
