SPARE PARTS
No.
Designation
Quantity(pcs)
1
Air cooler
1
2
instruction manual
1
3
remote control
1
TECHNICAL PARAMETERS
MODEL
FRE125
Ratings
220-240V/50Hz 200W
MAX Air Flow Consumption
2500m³/h
MAX Water Volume
30L
Net Weight
11.7 KGS
Measurements
378X442X1240mm
MODEL UV BULB
E17-3W Mini UV bulb
Ratings
AC 10V 3W
Note: Due to constant development of our products in regard to specification and design, we take
reservation for changes without prior notice.
OPERATION INSTRUCTION
1. Pull the unit outwards from the carton and place it on the floor.
2. Check if the spare parts are complete, same as the spare part list.
3. Place the unit on the floor.
Note: Two wheels with stopper are for the two front holes and Two wheels
without stopper are for the unit.
4. Pull out the cover of water inlet to fill with water (shown as fig.1).
