ELECTRIC TOILET.
Your boat has an electric toilet with a wastewater tank (Fig.10)
Fig.10
1- wastewater tank 54L
2- self-priming macerator (43 l/min)
(emptying the wastewater tank
overboard)
3- outlet for emptying wastewater tank
4- vented loop with valve
5- inspection hatch (on the locker
under the seat)
6- inlet ventilation of the wastewater
tank
7-active carbon filter
8-toilet with built-in electric pump
9- inspection hatch
10- inspection hatch
11- ball faucet 2 for wastewater
discharge (3/4”)
12- ball faucet 1 for water intake (1/2”)
13- scoop strainer
14- toilet control panel
15- wastewater tank fill level indicator
16- macerator switch (emptying the
wastewater tank overboard)
