CAMERA SETTING:
Press MENU for over 1 second to enter SETUP MENU.
Use UP/DOWN to move up and down and use -/+ to move left and right in SETUP MENU and
each sub menu.
Press MENU to go back to the previous menu when in SETUP MENU or each sub menu.
1. CAMERA SETTING
CAM1
CAM2
CAM3
CAM4
NOR/MIR: [MIRROR;NORMAL]
UP/DOWN: [UP;DOWN]
NAME: [CAM1]
SORT: [NORMAL;SHUTTER;
TILT.MT;TILT.AT]
NOR/MIR: [MIRROR;NORMAL]
Each camera’s Normal/Mirror view can be selected.
UP/DOWN: [UP;DOWN]
Each camera’s converted image display (top and bottom).
NAME: [CAM1]
Change the name of the camera.
SORT:[NORMAL;SHUTTER;TILT.MT;TILT.AT]
Select different function of camera.
2
TRIGGER MODE:
2. TRIGGER MODE
TRIGGER1
TRIGGER2
TRIGGER3
TRIGGER4
TRIGGER5
SOURCE:[CAM1~CAM4; AUX1~2; SPLIT1~3]
DELAY:[0~20sec]
SCALE:[ON;OFF]
DISPLAY SCALE
Up to 5 triggers can be set and each trigger source (CAM1~SPLIT3) can be selected. When trigger is
activated, the selected source’s image is displayed.
SOURCE:[CAM1~CAM4; AUX1~2; SPLIT1~3]
Select the source item for the trigger.
DELAY:[0~20sec]
Each trigger’s delay time is adjustable from 0 to 20 seconds.
SCALE:[ON;OFF]
ON/OFF setting for distance marker when any trigger is activated.
DISPLAY SCALE
Adjustable Position and Width setting for distance marker.
5 Operations
