Troubleshooting
Need Assistance? Go to BRIGGSandSTRATTON.COM or call 1-800-233-3723 (in USA).
Specifications
Engine Specifications
Model 100000
Displacement 9.93 ci ( 163 cc)
Bore 2.688 in (68.28 mm)
Stroke 1.750 in (44.45 mm)
Oil Capacity 15 oz (0.44 L)
Tune‐up Specifications *
Model 100000
Spark Plug Gap 0.030 in (0.76 mm)
Spark Plug Torque 180 lb‐in (20 Nm)
Armature Air Gap 0.006 - 0.014 in (0.15 - 0.36 mm)
Intake Valve Clearance 0.004 - 0.008 in (0.10 - 0.20 mm)
Exhaust Valve Clearance 0.004 - 0.008 in (0.10 - 0.20 mm)
* Engine power will decrease 3.5% for each 1,000 feet (300 meters) above sea level and
1% for each 10 F(5.6 C) above 77 F(25 C). The engine will operate satisfactorily at
an angle up to 15. Refer to the equipment operator's manual for safe allowable
operating limits on slopes.
Common Service Parts n
Service Part Part Number
Air Filter 593260
Air Filter, Pre‐cleaner 594055
Oil - SAE 30 100113
Advanced Formula Fuel Treatment & Stabilizer 100117, 100120
Resistor Spark Plug 594056
Spark Plug Wrench 19576
Spark Tester 19368
n We recommend that you see any Briggs & Stratton Authorized Dealer for all
maintenance and service of the engine and engine parts.
Not for
Reproduction

Briggs & Stratton 650 Series Specifications

General

Displacement	190 cc
Starting System	Recoil
Cooling System	Air-cooled
Lubrication System	Splash
Power Output	5.5 hp
Engine Type	4-stroke OHV
Oil Capacity	0.6 liters
Bore x Stroke	68.3 mm x 51.8 mm
Fuel Type	Unleaded gasoline
Bore	68.3 mm
Stroke	51.8 mm
Torque	6.50 ft-lbs
