UNIT LAYOUT - EXTERNAL
ENGLISH
1 2 3 4 5 6 7 8 9
10
Up
Pump Stop
Forward/Accept
See/Jump
Program
Down
Test
Back
Prime
Unit Type
Total Wash Programs
Current Program
(Formula) Number
Customer Name
00000 L10 01
BRIGHTWELL
UNIT LAYOUT - KEYPAD & SCREEN
Signal Indication
?
Formula
Select
(13mm)
Formula
Select
(13mm)
LCD Display
LCD Display
Supply
entry
(20mm)
Low Level
Alarm entry
Supply
entry
(20mm)
Highflow Pump
Double Pumphead
Pump 1 - Rear CW
Pump 2 - Front CCW
Keypad
Screw
Cover
Low Level
Alarm entry
5E
-
BRIGHTLOGIC LAUNDRY SYSTEMS BRIGHTLOGIC LAUNDRY SYSTEMS
Note: Suitable cable glands and cable size should be used to ensure that the units IP rating is kept.
