INSTALLATION - MOUNTING
Fix the unit to a vertical wall using the screws provided.
Ensure that the unit is level and positioned no more than 2 metres above the base of the product, which is to be
dispensed.
Important Notes.
Maximum recommended suction and delivery tubes - 2 metres
Minimum tube size - 8x11mm
Screw pitch / Drilling diagram - on next page
MAXIMUM
2 Metres
6mm
x 3 per Enclosure
ENGLISH
7E
-
