9
• Press
1
. ‘User Menu’ opens
• Select ‘User Settings’ by turning
1
• Press
1
. ‘User Settings’ opens
• Select ‘Periods’ by turning
1
• Press
1
. ‘Periods’ opens
• Select ‘P2: week/weekend’ by turning
1
• Press
1
, ‘P2: week/weekend’ opens
You can choose between ‘Week’ and ‘Weekend’. With ‘Week’
you can set a day program for Monday through Friday. With
‘Weekend’ you can set a day program for Saturday and
Sunday.
Week
• Select ‘Week’ by turning
1
• Press
1
. ‘Week’ opens
(*) You have a choice from ‘Period 1’, ‘Period 2’, ‘Period 3’,
‘Period 4’, ‘Period 5’ and ‘Period 6’. Every period is a part of
the day in which you can set a ventilation mode.
Perform the following actions to set period 1:
• Select ‘Period 1’ by turning
1
• Press
1
, ‘Period 1’ opens
• Select ‘Start Time’ by turning
1
• Press
1
, ‘Start Time’ opens
• Change the start time by turning
1
You have a range of between 3.00 hrs and 2.59 hrs
• Press
1
to conrm the start time
Now set the ventilation mode for period 1.
Perform the following actions for this:
• Select ‘Vent mode’ by turning
1
• Press
1
, ‘Vent mode’ opens
• Set the ventilation mode for period 1 by turning
1
• Press
1
to conrm the airow for period 1
You have set the ventilation mode for period 1 You can set
period 2 through 6 in the same manner. A period ends when
a new one starts.
Weekend
• Follow the steps from paragraph 4.3.3, until you have a
choice between ‘Week’ and ‘Weekend’
• Select ‘Weekend’ by turning
1
• Press
1
. ‘Weekend’ opens
• Continue the steps from paragraph 4.3.3 at (*)
4.3.4 Creating a P3 program (see
1
)
• Press return
2
as many times as necessary to get to the
main screen
• Press
1
. ‘User Menu’ opens
• Select ‘User Settings’ by turning
1
• Press
1
. ‘User Settings’ opens
• Select ‘Periods’ by turning
1
• Press
1
. ‘Periods’ opens
• Select ‘P3: day’ by turning
1
• Press
1
, ‘P3: day’ opens
(*) You can choose from the days between ‘Monday’ through
‘Sunday’. You perform the following steps to set a day
program for Monday:
• Select ‘Monday’ by turning
1
• Press
1
. ‘Monday’ opens
You have a choice from ‘Period 1’, ‘Period 2’, ‘Period 3’,
‘Period 4’, ‘Period 5’ and ‘Period 6’. Every period is a part of
the day in which you can set a ventilation position.
Perform the following actions to set period 1:
• Select ‘Period 1’ by turning
1
• Press
1
, ‘Period 1’ opens
• Select ‘Start Time’ by turning
1
• Press
1
, ‘Start Time’ opens
• Change the start time by turning
1
You have a range of between 3.00u and 2.59u
• Press
1
to conrm the start time
Now set the ventilation mode for period 1.
Perform the following actions for this:
• Select ‘Vent mode’ by turning
1
• Press
1
, ‘Vent mode’ opens
• Set the ventilation mode for period 1 by turning
1
• Press
1
to conrm the ventilation mode for period 1
You have set the ventilation mode for period 1 You can set
period 2 through 6 in the same manner. A period ends when
a new one starts.
If you have created a day program for Monday, you can do
the same for the other days of the week. Then repeat the
steps from paragraph 4.3.4, but, after (*) choose another day
instead of ‘Monday’.
4.4 Activate programme type (P1, P2 or P3)
The WTW control has three types of weekly programs P1, P2
and P3. You can program the weekly programs by yourself,
for more information see paragraph 4.3.
Perform the following actions if you wish to program one of
the weekly programs (see
1
):
• Press return
2
as many times as necessary to get to the
main screen
• Press
1
. ‘User Menu’ opens
• Select ‘User Settings’ by turning
1
• Press
1
. ‘User Settings’ opens
• Select ‘Active Program’ by turning
1
• Press
1
. ‘Active Program’ opens
• Select P1, P2 or P3 by turning
1
• Press
1
to activate P1, P2 or P3
4.5 Temporarily overriding program
You can temporarily override the program. You need to
perform the following actions for this (see
1
):
• Press return
2
as many times as necessary to get to the
main screen
Turn
1
to temporarily set the ventilation mode
Take note! It is stated at the top of your screen, how
long the newly set ventilation mode applies. The
program will be enabled again after this period of
time. The override period will be 30 minutes if you
overruled the device in the maximum position. You
can also undo this by pressing return
2
.
