PARTS LIST - Pitmaster
®
deluxe:
2 Right Legs
2 Left Legs
1 Shelf
1 Axle
2 Wheels
2 Wheel Caps
2 Leg Braces
1 Firebox Support
1 Grill Base
1 Front Shelf
2 Front Table Supports
1 Charcoal Tray
1 Charcoal Grate
2 Charcoal Grate Adjusters
3 Cooking Grills
1 Warming Rack
1 Grill Lid
1 Smokestack Bracket
1 Smokestack
1 Smokestack Damper
1 Spring
1 Temperature Gauge
1 Grill Lid Handle
1 Firebox Lid Stop
1 Firebox Lid
1 Firebox Lid Handle
1 Push Handle
2 Firebox Cooking Grills
1 Firebox Door Hinge
1 Firebox Door
1 Firebox Air Shutter
1 Firebox Charcoal Grate
1 Firebox Door Latch
1 Firebox Base
1 Grease Cup Holder
35
34
33
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
16
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
ASSEMBLY INSTRUCTIONS
READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING OR OPERATING YOUR GRILL.
FOR MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 800-527-0717.
(Proof of purchase will be required.)
Inspect contents of the box to ensure all parts are included and undamaged.
3
We recommend two people work together
when assembling this unit.
The following tools are required to assemble
this Pitmaster
®
deluxe:
• Pliers
• Phillips & Flathead Screwdrivers
• Adjustable Wrench
