23
Step 7
Install door bracket using four
M6 X 12mm bolts. Make sure door
stop is set toward back of cart.
Step 8
Insert right side door over lower
pivot (on bottom cart panel) then
align door with cart frame. Depress
spring pin located on top edge of
door and slide door toward side
cart panel until spring pin locks into
hole in door bracket. Repeat for
other door.
Door bracket
Spring Pin
Lower Pivot
To Next Page
