12.
Figure 6.
FAN ADJUSTMENT
6a. Adjust fan upwards on shaft as close as
possible to the bottom of the hopper with-
out touching during operation.
Note: The fan and fan driver normally rests on
the spring pin, but may be adjusted
upward approximately 1/8 of and inch.
If neccesary, adjust
fan upwards on shaft
as close as possible to
the bottom of the hop-
per without touching
during operation.
