Brinly BS-36 - Page 13

L-1884-E 13.
Figure 7.
INSTALL AGITATOR
7a. Place O-Ring (20) over transmission
shaft. Slide down to hopper bottom to cre-
ate seal.
7b. Slide Agitator Spring (20) over transmis-
sion shaft.
7c. Insert Cotter Pin (18) through hole at top
of transmission shaft. Flair ends to keep
in place, as shown.
18
18
Cotter Pin, 1/8”x1”
Qty. 1
19
Agitator Spring
Qty. 1
20
O-Ring 3/8”
Qty. 1
19
20
18
19
20
ASSEMBLY
