Brinly SAT2-40BH-P User Manual

6 1019101-E
English Manual
================================================================================================
Do not return this product if you are missing parts.
Please Call: 1 (877) 728-8224
HARDWARE IDENTIFIER
Illustrations on this page are to scale for faster identication of hardware during assembly.
19
Bolt; Hex Head, 1/2” x 3” (x2) . . . . . . . . . . . . . . . . . . .
1M1648P
Drawbar Pin; 1/2" x 2 1/2" (x1) . . . . . . . . . . . . . . . . . . . . . . . . . . .
B-3861
17
Bolt; Carriage,
5/16 x 2”
(x2) . . . . . . . .
10M1032P
30
Bolt; Carriage
SS, 1/4 x 1-1/2”
(x1) . . . . . . . . . . .
11M0824P
31
Washer; Flat
5/16” (x6) . . . . . . . . . . . . . .
45M1111P
27
Washer; Thick
5/8” (x10) . . . . . . . . . . .
1019390
16
Washer; Flat
1/2” (x4) . . . . . . . . . . . .
21
1019753
Washer; Thin
5/8” (x2) . . . . . . . . . . . . .
1019391
26
Nut; Hex 1/2” (x2) . . . . . . . . . . . . . .
30M1600P
20
24
Nut; Nylon Lock, 1/4-20” (x2) . . . . . . .
B-1673P
Nut; Hex Lock 1/2” (x2) . . . . . . . . . .
B-5096Y
28
Nut; Hex Lock, 5/16” (x16) . . . . . . . . .
B-4786
15
Bolt; Hex Head
5/16 x 1” (x2) . . . . . . . . . . . .
2M1016P
14
22
Transport
Lock Pin (x1) . . . . . . . .
B-3307-S
23
Bolt; Hex Head
1/4 x 1-1/4” (x1) . . . . .
2M0820P
Bolt; Hex Head
5/16 x 3/4” (x10) . . . . . . . . . . . . .
2M1012P
13
Washer; Lock
5/16” (x1) . . . . . . . . . . . . . . .
40M1000P
33
Nut; Hex, 5/16” (x1) . . . . . . . . . . . . . . .
30M1000P
34

Brinly SAT2-40BH-P Specifications

General

Brand	Brinly
Model	SAT2-40BH-P
Category	Tiller
Language	English
