Section 5 Maintenance
Drive Belt
The dive belt is considered a wearable item.
Replacement intervals depend on vehicle use and
environment. If your belt is slipping you may need to
replace it.
1. P brake,
place shifter in Neutral, turn off ignition switch,
and remove switch key.
2. Remove the upper belt covers. (It is not
tom cover.
own in
ark vehicle on a level surface, set park
necessary to remove the bot
3. “Walk” the belt off of the rear pulley as sh
Figure 5-6.
Figure 5-6
4. Install the new belt on the front pulley first and
“walk” it onto the rear pulley.
5. Reinstall the belt guards. Figure 5-7.
rds may
void your warranty.
Attention: Failure to reinstall the belt gua
Figure 5-7
19
