e
Num Nu
dels
Requir
Referenc
ber
Part
mber
Part Description – 4x4mo
Quantity
ed
1 45501 Frame, CW413 - 4x4 1
2 45401 Rear frame stub, CW - black 2
50168 5/16 x 2-1/4" USS Socket Head bolt 2
50007 nut, 5/16 nylock 2
/16 50702 bent washer 5 2
3 45413 Bumper, CW - black 1
45433 Bumper, Trail Wagon – with grill guard - Black
50167 bolt, 5/16 x 2 4
50007 nut, 5/16 nylock 4
50702 bent washer 5/16 4
70208 Vinyl Caps 1 3/4 x 1 1/2 2
4 45412 Brush guard roof, CW - black 1
50168 5/16 x 2-1/4" USS Socket Head bolt 4
50007 nut, 5/16 nylock 4
50702 bent washer 5/16 4
5 45411 Brush guard seat back, CW - black 1
50168 5/16 x 2-1/4" USS Socket Head bolt 2
50007 nut, 5/16 nylock 2
50702 bent washer 5/16 2
6 43007 A-arm 4x4, CW – black (left or right) 2
51100 suspension bushings 2 ea
50266 bolt, 5/8 x 9 1/2" 1 ea
50015 Nut, 5/8 nylock 1 ea
45150 Spacer/CW A-arm bushing-4x4
7 25001 Strut assembly, left 1
25009 Strut assembly, right 1
50028 Nut, 7/16 NF jam 2
50041 Nut, 3/8 NF slotted 2
50801 cotter pin 1/8" x 1 2
7a 25020 Lower ball joint 2
8 25003 strut bearing 2
50163 bolt, 5/16 x 3/4" NC 8
50005 Nut, 5/16 keps 8
9 25002 Hub / rotor 4x4 2
50040 Nut, 5/8 NF slotted 2
30621 cotter pin 2
30623 dust cap 2
50060 Lug nuts, 1/2" 16
11 70301 Shock, Heavy duty #1 4
50400 Bolt, 10 mm x 40mm 6
50404 10 mm x 70mm bolt 2
50065 Nut, 10mm nylock 8
spacer, shock 2
12L bly, UTV 22/9-10" Left 30122 Rim/Tire Assem 1
12R 30123 im/Tire Assembly, UTV 22/9-10" Right R 1
30480 Wheel rim, 10" x 6"
30195 Tire, Pathfinder 22/9-10"
58
