Reference Part
er
Part Description – 4x4models
Quantity
Number Numb
Required
13L 30124 Rim/Tire Assembly, UTV 22/11-10" Left 1
13R " Right 30125 Rim/Tire Assembly, UTV 22/11-10 1
30480 Wheel rim, 10" x 6"
30194 Tire, Pathfinder 22/11-10"
14 20851 CV half shaft (axle) – (Left or Right) 2
20868 Boot CV
15 tial – 4x4 20839 front differen 1
20848 Hilliard Front Differential Replacement Oil
50206 Bolt, 3/8 x 1 4
50740 washer, 3/8 flat 4
50741 washer, 3/8 lock 4
16 25006 drive shaft, front 1
50092 bolt, ¼ x 2” 2
50003 nut, ¼ keps 2
17 25008 bearing, shaft support 1
50163 bolt, 5/16 x ¾” NC 2
50005 Nut, 5/16 keps 2
18 25007 drive shaft, rear telescoping 1
50631 Screw, 3/8” – 16 x ½” square head set 2
10184 key, 3/16 x 1 3
19 g 17 inch 20804 convoluted tubin
20 10591 Rack & pinion with rod ends 4x4 1
10593 Rack & Pinion Boots 2
50171 Bolt, 5/16 x 3 3/4" USS 4
50005 Nut, 5/16 keps 4
21 10594 Rod end 4x4 2
10595 Tie rod 4x4 2
10593 Rack boot 2
22 10592 Steering Shaft w/u-joints 4x4 1
50402 Bolt, 10mm x 30mm 1
50066 Nut, 10mm Tri Lock Jam 1
50403 Bolt, 8mm x 30mm 1
50780 Lock washer, 8mm 1
23 45422 Steering Stub Shaft Assembly, CW - Black 1
24 pport, CW - black 45400 Steering su 1
51100 suspension bushings 2 ea
50152 bolt, 5/16 x 1 4
50005 Nut, 5/16 keps 4
2 5 10502 Steering Wheel 13" 1
10506 Center cap
screw, black center cap
50081 bolt, 1/4 x 1 3/4 3
50001 nut, 1/4 nylock 3
30 - black 45402 Pedal assembly, CW 1
50152 olt, 5/16 x 1 b 6
50081 olt, 1/4 x 1 3/4" b 1
50159 bolt, 5/16 x 1 1/2 1
50005 Nut, 5/16 keps 8
50701 Washer, 5/16 flat 2
59
