8 ENGLISH
D a) Insert the appropriate gasket (3/8”) into the 3/8” end of the
hose (2) and connect the 3/8” end of the hose (2) to the outlet
of the filter head, labelled with an “OUT” arrow.
b) Make sure all connections are tightened properly. Avoid over
tightening.
c) Turn on the cold water supply.
!
The max. tightening torque for the G3/8" connections
may not exceed 14 Nm! Only hose connections with
gaskets (5) may be used, because hoses with conical screw
connections damage the connections of the filter head and
invalidate any warranty claims!
Hose 2:
800 mm
C
3/8"
B
3/8"Hose 1:
800 mm
A
3/8"
or Adapter
D
(fig. 6)
supply
Existing
kitchen tap
