Britax Affinity - Assembly; Stroller Frame; Front Wheels; Rear Wheels

6 7
Assembly
Stroller Frame
1. Release the chassis lock and open the
stroller frame.
2. Lift the handle until the frame locks into
the upright position.
3. Push down on the handle to ensure
that the frame is secure.
Front Wheels
Installing the Front Wheels
1. Slide the front wheel mounting pins
into the housings on the frame until
they lock into place.
2. Pull both wheels to ensure they are
secure.
Removing the Front Wheels
1. Push the front wheel release button
and remove the wheel.
Rear Wheels
IMPORTANT: Always ensure the correct air pressure in the rear
wheels. Maximum air pressure is 25 psi (172 kpa or 1.72 bar).
Installing the Rear Wheels
1. Slide the rear wheel axle into the rear
wheel hub mounting bracket until it
locks into place.
2. Pull both wheels to ensure they are
secure.
Removing the Rear Wheels
1. Press the rear wheel release button
and pull out the wheel at the same
time.
