Britax Affinity - Stroller Seat; Child Arm Bar

8 9
Stroller Seat
Installing the Stroller Seat
1. Align the Click & Go connectors on the
stroller seat with the receivers on the
stroller frame and press down until a
click is heard.
2. Pull up on the stroller seat to ensure
that it is secure.
NOTE: Stroller seat can be attached in
either a forward or rear-facing position.
Always ensure that the Click & Go connectors are fully connected
before using the stroller.
Removing the Stroller Seat
IMPORTANT: Always remove your child from the seat before
detaching from the stroller.
1. Lift both release levers on the Click &
Go connectors.
2. Lift the seat away from the Click & Go
receivers on the stroller frame.
Child Arm Bar
Installing the Child Arm Bar
1. Slide the pins into the mounts on the
seat until they lock into place.
Removing the Child Arm Bar
1. Press the buttons underneath the
seat connectors and pull the arm bar
forward.
NOTE: Arm bar can be opened
from either side of the seat without
removing.
