Adjusting the Harness
IMPORTANT: The harness can be adjusted to three dierent heights.
Always ensure proper adjustment at or above your child’s shoulders.
1. Pull the harness strap retainer away
from the seat back and turn 90
degrees to feed it through the harness
slot.
2. Push the harness retainer through the
appropriate harness slot to the back of
the seat.
3. Turn the harness retainer to its original
position as shown so it properly retains
the harness.
Using the Harness
IMPORTANT: Shoulder and waist straps separate for care and
maintenance, but should always be used together to secure
your child.
1. Align the tongues on the waist straps
with the retainers of the shoulder
straps and slide through until they lock
into place.
2. Insert the tongues into the buckle
assembly until a click is heard.
CLICK
Canopy Vent
1. Fold the canopy vent forward to
access additional ventilation.
