33
HOW TO USE
G. Ensure slack is removed from harness lap strap by pulling
shoulder straps then pull harness adjustment strap to achieve
a comfortable but firm fit. Ensure that any slack in harness
straps is removed. Shoulder harness straps must fit firmly to
the child. A loose harness could result in serious injury in an
accident. Do not over tighten.
Do not use the restraint if straps do not tighten, contact your
local authorised service agent for repair.
Tongue
Buckle
Harness
Lap Straps
Shoulder
Straps
Crotch
Straps
Pull to remove slack from harness
lap straps
F. Fit either harness tongue into the harness buckle followed by the other tongue. A click is heard when the
last tongue is fully engaged.
Should the second tongue not engage - press the red button and reinsert the tongues. Ensure secure
engagement by pulling harness straps. If the harness buckle does not engage correctly then it may require
cleaning or seek replacement - refer to page 55. The buckle tongues are fully engaged when both
tongues are inserted and a 'click' is heard.
BABY USE REARWARD FACING
Pull to remove
slack from harness
lap straps
Click
