CARE & MAINTENANCE
TO REPLACE COVER
1. Align and fit cover over restraint starting at top. Attach elastic loops.
2. Refit fabric overhang.
3. Feed shoulder Harness Straps through the lap strap slots.
4. Feed Crotch Buckle through slot in cover whilst fitting the cover at the lower part of the seat.
5. Re-attach Plastic Clips at the front of the seat.
6. Refit the harness straps by feeding through the appropriate shoulder strap slots. You MUST thread the
shoulder strap over the cross bar and then re-attach the straps to metal strap connector at the back of
the seat (see page 46). Refit any Head Roll or Padded Insert with slots whilst refitting the harness.
E
F
A
G
B
C
D
B
