63
INSTALLATION OF CAR
ANCHOR FITTING
Measure distance from restraint
upper anchorage attachment clip
to the car anchor fitting.
The shaded areas of this diagram illustrate the possible locations of the anchor fitting. Within each shaded
area is an anchor fitting showing the correct way to install the fitting. Ensure the anchor fitting is aligned as
illustrated unless stated otherwise in the vehicle owner’s handbook.
Adjustable upper
Anchorage strap.
Front of Vehicle
45°
Extension Straps
Length 300mm (Use Britax Safe-n-Sound part 0035 or 0291).
Length 600mm (Use Britax Safe-n-Sound part 0036 or 0290).
Available from all major child restraint retailers.
