Adjusting the seat width
Adjusting the width of the seat is only possible when using the
Porsche Zoom on the front passenger seat. When using the
Porsche Zoom on the rear seat, always move the side arm rests
in fully.
Before the child uses the Porsche Zoom, the seat must be adjusted
to the width of the child’s pelvis as follows:
Unlock the seat lock on the underside by opening the retaining
flap (fig. Ill, l), allowing the arm rests (fig. V,2 ) of the Porsche
Zoom to move in and out. Now adjust the arm rests to the seat
width of your child as shown in Figure V and engage the seat Jock
b
Y
folding down the retaining flap, The arm rests should stt as
c ose to the child’s pelvis (the widest part of the chi!d’s hipsI,as
possible to ensure the lap belt runs properly, but wlthout bemg
too tight or restrictive for the child.
After you have engaged the lock, let the child t sitting on the
seat cushion and assure you have a comfortab e but snug fit. 7
Should the adjustable arm rests become loose as time goes
dy, they can be re-adjusted. To do this, proceed as follows:
a) Open retaining flap and move the arm rests fully out.
b) Close retaining flap.
c) Carefully tighten the screws (fig. IV, 3) approx. 1 turn
clockwise. Do not over tighten the screws or you may
damage the plastic parts.
d) Now adjust the seat cushion to the width of the child’s pelvis
as described above.
Zoom”
Child Booster Seat
For Children from 37-100 Ibs
Britax Model 431-13
includes Airbag Disconnection Belt for Porsches
Porsche Zoom
Instructions on installation and use
Please read throu h these instructions carefully before using the
Porsche Zoom.
B
he Porsche Zoom is suitable for protecting
children between the a es of 4 and 12 years or weighing between
37 and 100 lb (17 an
cf
45 kg).
WARNING!
It is possible to secure the child or Porsche Zoom in the
car incorrectly. This could cause severe injury or death if
there is an accident. Therefore please read through the
following information carefully and make sure that
- the Porsche Zoom is secured with the seat belts as
described in the instructions.
- the disconnection belt tongue is inserted in the
disconnection belt buckle in front of the Porsche front
passenger seat to turn off the front passenger airbag.
The Porsche Zoom should always be used in the rear seat and in
conjuncfion with a lap and shoulder belt. The disconnechon belt
on the Porsche Zoom has no function there.
Under no
circumstances can the Zoom be fastened with only a lap
b- .
2 pomt) belt. If necessary (2-seat cars) Porsche test@
as shown that the Zoom may be used In a Porsche with
an airbag, if the seat is moved all the way rearward. Porsche
strongly recommends that the air bag be turned off by
insertmg the air bag disconnection belt ton ue
1
on the
Porsche Zoom into the disconnection belt but le In front
of the front passenger seat.
This adapter device must be
installed by an authorized Porsche dealer when purchasing the
Porsche Zoom. If our vehicle has a seat belt with an
automatlc
locking retractor (
x
LR) you may want to engage
it to help prevent
unwanted movement of the child seat during normal drlvlng.
Furthe,r information OIJ this can also be found in th! car
&s;JEslanual under Child Restraint Systems and Alrbag
2
Securing the child in the Porsche Zoom on the rear seat
a) Ensure that the arm rests are adjusted fully in. Place the Porsche
Zoom on the seat and have the child sit in the Porsche Zoom.
b) Fasten the lap and shoulder belt, ensuring that the shoulder belt
portion passes over the child’s collarbone (fig. I, II).
c) The lap belt portion must pass as low as possible over the child’s
pelvis and
under
the arm rests (fig. I, 4).
For smaller children, when the belt does not pass over the collarbone,
the shoulder belt should be correctly positioned by the belt holder
clip (fig. II, 5) of the back belt. This prevents the shoulder belt from
sitting too close to the neck.
ushed fully into the
Pull on the lap and shoulder belt until it fits the child snugly and does
not twist.
Securing the child in the Porsche Zoam on the front
passenger
seat
Porsche testing has shown the Porsche Zoom may also be used on
the front passenger seat with the passenger seat moved to Its
rearmost position.
Porsche strongly recommends that the air
bag be turned off by insertin the air bag disconnection belt
tongue on the Porsche Zoom fig. II, 9) into the disconnectlon
‘i-
belt buckle in front of the front passenger seat (fi
.
This adapter device must be Installed by an authorized
f
II, 8).
orsche
dealer when purchasing the Porsche Zoom.
Warning: Never use this Porsche Zoom in the front seat of
any non-Porsche vehicle unless the airbag is off!
Porsche ZoomTM Child Booster Seat page 1 of 3
