15
D. The minimum number of outlets that should be fully open for floor/ceiling systems where the system has zone
dampers installed, and these zones are being operated from a Brivis Networker Thermostat using the heater’s
on-board zone relays or a Network 516 module. Systems fitting this description are deemed to have
Adaptive Zoning active, hence minimum outlet numbers are reduced. Where it shows half figures such as 1.5, it
is possible to operate with 1 outlet fully open, and another outlet half closed (such as a bathroom). Refer to
Section 13 for balancing guidelines.
*Note: Column D only applies to StarPro Max/Plus heaters and should not be used unless the Brivis Networker
has been configured for Adaptive Zoning only. If not refer to column C instead.
Note: For StarPro Max/Plus Internal model
s,
the normal return air pop configuration is side entry, but can be
changed to the end of the fan cabinet if necessary. If this is done, a total of two outlets must be removed from
the allowable maximum number of outlets.
Outlet Register Chart
13. Thermostat Installation
All Brivis heating systems can be controlled by various Brivis Thermostats, each explained in detail below. A
Thermostat inside the house is wired to the control module in the heater. The Thermostat monitors the temperature
in the house, and switches the system ON and OFF in order to maintain a set temperature. So it must be positioned
correctly.
**Note: Airflow figures are based on a total static pressure of 125 Pa for 26, 28, 30 & 35 models, and 50 Pa for other models.
System
Airfl ow
Rate
(L/s)**
ABC D*
Model
Maximum Ceiling Typical Floor
Minimum
Floor/Ceiling
Minimum
Floor/Ceiling (Adaptive
Zoning Only)
StarPro Plus/Max Heaters
External
HX30E 850 15 23 73
HX30E-XA 985 17 23 73
MX30E 960 16 23 72
MX30E-XA 965 17 23 72
HX23E 715 12 12 52
HX23E-XA 755 13 12 52
MX2IE 700 12 12 5 1.5
MX2IE-XA 740 13 12 5 1.5
Internal
HX35I 1130 17 24 7 2.5
MX35I 1160 17 24 7 2.5
HX30I 1065 16 22 73
HX30I-XA 1095 17 22 73
MX30I 1080 17 24 72
MX301-XA 1140 17 24 72
HX23I 765 12 13 52
HX23I-XA 795 14 13 52
MX21I 785 12 13 5 1.5
MX21I-XA 830 14 13 5 1.5
HX15 695 12 13 5 2
B-Max Heaters
BH28EN 710 13 12 73
BH20EN 420 7 10 52
Classic Heaters
Buffalo - External
B26 815 11 16 8 N/A
B26 XA 1060 13 16 8 N/A
B20 490 8 11 6 N/A
B20 XA 585 10 11 6 N/A
B15 490 8 9 5 N/A
2P Wombat - Internal
2PW26 940 13 16 8 N/A
2PW26 XA 1025 15 16 8 N/A
2PW 20 590 11 11 6 N/A
2PW 20 XA 780 14 11 6 N/A
2PW 15 530 10 9 5 N/A
Upfl ow/Downfl ow - Internal N/A
U26 1050 13 16 8 N/A
U26 XA 1170 15 16 8 N/A
U20/D20 540/525 8 11 6 N/A
U20/D20 XA 605/560 10 11 6 N/A
