BRKT ARM3780HD - Step 4: Attach Mount Bracket to Arm Assembly; Attaching Bracket with Assistance Required; Step 5: Secure Monitor Plate to Arm Assembly; Securing Monitor Plate Components to Arm

P 10
B
Heavy, Assistance
Required
TRES LOURD ! Cette etape
requiert deux personnes
!PESADO! Necesitara ayuda para
realizar esta operacion
A3
A2
Secure Acorn Nut
and Washer on
Monitor Plate to
Arm Assembly
M6 Washer
M6 Nylon Nut
Allen Wrench
A2
A1
A3
A1
A1
X
2
STEP 4- ATTACH UNIVERSAL MOUNT BRACKET TO ARM ASSEMBLY & WALL
BRACKET
STEP 5- SECURE MONITOR PLATE TO ARM ASSEMBLY
