BRKT ARM3780HD - Step 1: Connect Universal Monitor Plate to Flat Panel; Flat Back Panel Connection; Curved Back Panel Connection

STEP 1- FLAT BACK FLAT PANEL (UNIVERSAL MONITOR PLATE)
Connect Universal Monitor Plate to flat panel
Conecte el adaptador al monitor
Connectez l'adaptateur au moniteur
STEP 1- CURVED BACK FLAT PANEL (UNIVERSAL MONITOR PLATE)
Connect Universal Monitor Plate to flat panel
Conecte el adaptador al monitor
Connectez l'adaptateur au moniteur
2
3
4
X4
8
8
9 10
X4
Spacers can also be used to
provide clearance for cables
and connectors .
1
2
3
4
5
6
7
P5
