Broadcom 95xx User Guide Broadcom
®
95xx PCIe 4.0 MegaRAID
®
and HBA Tri-Mode Storage Adapters
Table 11: External Adapter Cable Pinout
Pin Signal Pin Signal
A1 No Connect C1 CMICLK
A2 CINT# C2 CMIDAT
A3 GND C3 GND
A4 PERp0, RX0+ C4 PETp0, TX0+
A5 PERn0, RX0- C5 PETn0, TX0-
A6 GND C6 GND
A7 PERp3, RX3+ C7 PETp3, TX3+
A8 PERn3, RX3- C8 PETn3, TX3-
A9 GND C9 GND
B1 PWR D1 PWR
B2 CBLPRSNT# D2 MGTPWR
B3 GND D3 GND
B4 PERp1, RX1+ D4 PETp1, TX1+
B5 PERn1, RX1- D5 PETn1, TX1-
B6 GND D6 GND
B7 PERp2, RX2+ D7 PETp2, TX2+
B8 PERn2, RX2- D8 PETn2, TX2-
B9 GND D9 GND
